Marking Metal Without Ink
Metal laser marking writes permanent marks on steel, aluminum, brass and titanium — no ink, no labels, no etching chemistry. The mark is in the metal itself, so it survives heat, oil and washdowns.
How the Mark Forms on Metal
A fiber beam at 1064 nm is absorbed by metal, so it anneals stainless black, etches a gray-to-dark contrast, or engraves depth — set by pulse, speed and frequency. For color on stainless or deep black on anodized aluminum, a MOPA source tunes the pulse for the effect.
Specs and Speed
Our fiber heads run 20W–100W at up to 10,000 mm/s with ±0.002 mm repeat accuracy, air-cooled and consumable-free, across fields of 100–300 mm set by the lens. More power means deeper, faster marks; the right level is matched to the part.
| Source | Wavelength | Best on | Heat | Typical use |
|---|---|---|---|---|
| Fiber | 1064 nm | metals, hard plastics | low | IDs, codes, logos on metal |
| MOPA | 1064 nm tunable | stainless color, anodized black | very low | color / fine marking |
| CO2 | 10.6 µm | wood, acrylic, glass, leather | medium | non-metal marking |
| UV | 355 nm | sensitive plastics, glass | minimal | medical, cosmetics, electronics |
Parts We Mark
Serial numbers, 2D codes and logos on steel and stainless, nameplates and tags, aluminum profiles, tools and fasteners, automotive and machinery parts.
CE Marking & Compliance
Every machine ships CE-marked, with conformity documentation available on request. We never claim SASO, SABER, GCC or UKCA we do not hold.
Fiber, MOPA or More
Most metal lines run fiber. Choose MOPA when color or anodized-black matters; step up in power for depth or volume. As a maker-backed integrated supplier, we’ll point you to the right one after a sample.
Request a Quote · Download the Spec Sheet
Explore: Stainless Steel · Aluminum · Portable for Metal · Applications. Related: Fiber Laser Marking · All Marking Machines.
1-year warranty; installation, training & after-sales support available.
